Swimming pools lose energy in a variety of ways, but evaporation is by far the largest source of energy loss. Evaporating water requires tremendous amounts of energy, how to choose a best solution to heat a swimming pool to keep the water temperature to be stable at 26 to 27℃？The solar energy, gas energy and electricity energy are the solutions we adopt in common.
Here is the content list:
ANALYSIS ON DIFFERENT ENERGY.
How can a heat pump save so much energy?
How to select a right model swimming pool collector?
The advantages of MICOE swimming pool heat pump.
Above comparison shows the advantage to adopt renewable energy of Solar water heating system and air source heat pump, but it also depends on the different application.
For example, if use solar water heating system to heat a swimming pool, it needs a lot of space to install big area solar collectors.
Meanwhile ,if use swimming pool air source heat pump, the installation can be easier.
Normally we use COP as a core value on a air source heat pump.
COP means Coefficient Of Performance.
From the technical data we can see that the COP is almost based on formula of:
COP = heat capacity ( Power output) / Power input
Why 1kwh electricity POWER INPUT can get many times POWER OUTPUT to heat the water？
1kwh electricity power input mostly consumed by the heat pump compressor, which compress the Refrigerant R32/R410a between Vapour & Liquid form to absorb plenty heat from Air and release to heat the water, see the attached diagram.
Normally a heat pump can get a COP between 4 to 7, why a heat pump with an inverter can get a COP up to 13 in summer time?
DC Inverter Pool Heat Pumps technology uses the reverse Carnot cycle principle to drive heat from a low-level heat source to a high-level heat source under the promotion of high-level energy, that is, to convert a heat source that cannot be directly used into an available high-grade heat source, thereby achieving partial savings. Disposable high-energy technology. The DC inverter pool heat pumps exchanges heat with the pool water through the continuous circulation of the refrigerant to heat the water.
The target temperature of a swimming pool is normally at 26 to 27℃, so the heat loss is calculated based on compensate the heat loss to keep the temperature.
Formula for heat loss calculation:
FAST MODEL SELECTION:
The advantages of MICOE swimming pool heat pump.
@ MICOE copyright reserved.
The all-in-one heat pump is a water heater that can provide the whole family with different hot water needs with large water volume, high water pressure, and constant temperature 24 hours a day, while consuming the least energy to complete the above requirements.
Here is the content list:
The working principle of the all-in-one heat pump
Features of all-in-one heat pump
Instructions for use of all-in-one heat pump
A complete all-in-one heat pump consists of 2 main parts: Manufacture the air-conditioning part and the heating hot water part. But in fact, these two parts are closely linked, inseparable, and must work at the same time. That is, while heating hot water, it cools the kitchen. In other words, while refrigerating the kitchen, it is also heating hot water.
Its internal structure is mainly composed of four core components: compressor, condenser, expansion valve, and evaporator.
The working process is as follows: the compressor compresses the returning low-pressure refrigerant and turns it into high-temperature and high-pressure gas and discharges it. The high-temperature and high-pressure refrigerant gas flow through the copper pipe wound outside
the water tank, and the heat is transferred to the water tank through the copper pipe to cool down. The down refrigerant becomes liquid under the continuous action of pressure. After passing through the expansion valve, it enters the evaporator. Because the pressure of the evaporator drops suddenly, the liquid refrigerant quickly evaporates and becomes a gaseous state, and absorbs a lot of heat. At the same time, under the action of the fan, a large amount of air flows through the outer surface of the evaporator, and the energy in the air is absorbed by the evaporator, and the temperature of the airdrops rapidly, turning into the cold air and discharged into the kitchen. Then the refrigerant that has absorbed a certain amount of energy flows back to the compressor and enters the next cycle.
1. Safety, because it is not directly heated by electric heating elements, compared with electric water heaters, it eliminates the potential safety hazards of electricity leakage; Compared with gas water heaters, there are no safety hazards such as gas leakage or carbon monoxide poisoning, so it has better safety performance.
2. Comfortable, the all-in-one heat pump is a heat storage type. The heating function is automatically activated according to the temperature in the water tank to ensure a sufficient supply of hot water for 24 hours. Therefore, there will be no problems that cannot satisfy multiple taps at the same time like a gas water heater. The problem is that the electric water heater has a small capacity and many people need to wait for a bath.
3. Save money, because its power consumption is only a quarter of that of an equivalent electric water heater, which is equivalent to using the same amount of hot water, using an all-in-one heat pump, and the electricity bill is only a quarter of the electric heating.
4. Kitchen refrigeration, is the biggest advantage, ordinary water heaters simply cannot have the function of refrigeration. If the kitchen needs additional cooling function, you need to buy a kitchen air conditioner. Because the kitchen has oily fume, it is a special environment, so the kitchen air conditioner is different from the ordinary air conditioner, and the price is much more expensive.
5. Green and environmentally friendly, the gas water heater heats hot water by burning combustible gas, and at the same time emits a large amount of carbon dioxide, sulfur dioxide, and other harmful exhaust gas. The all-in-one heat pump just transfers the heat from the surrounding air to the water, completely achieving zero emissions, and has almost no impact on the environment. It is a true environmentally friendly water heater.
6. Low-carbon fashion, as energy-saving and emission reduction, has become the trend of the times, saving energy and reducing carbon emissions is the most fashionable way of life.
Installation: The all-in-one heat pump is usually installed on the balcony of the kitchen, and the air outlet is connected with the kitchen through the air duct so that the cold air blown out can directly enter the kitchen to achieve the cooling effect. During installation, only the hot and cold water outlets are connected with the reserved hot and cold water in the house, and they can be used by connecting them. The installation is very simple.
Operation: All-in-one heat pumps mostly use microcomputer intelligent controllers, which have time setting, timing switch function, water temperature setting, ventilation setting, overheating protection, and other intelligent control functions. However, most of the functions have been set by the manufacturer at the factory. Just use the default values. Basically, you only need to set the temperature you need (usually set at 45-50 degrees) and you can use it.
It is the responsibility of each manufacturer to produce an industrial all-in-one heat pump that meets the standards, so as to ensure the safety of the use of all-in-one heat pumps and the healthy development of the all-in-one heat pump market. MICOE many tests on all-in-one heat pumps before they leave the factory, and the quality qualification rate is guaranteed. If you are in the all-in-one heat pump business, you can consider our cost-effective products.
Hosted by real estate outstanding CEO students association of Qinghua University and China real estate investment and financing alliance,sponsored by credit China union committee,the 2013 2nd China Real Estate Summit Forum was grandly open in Nanjing Green Intercontinental Hotel.The vice minister of Jiang Su united front work department and party group secretary of the federation of industry and commerce Shao Jun,the deputy party secretary of Qinghua continuing education institute Yan Guizhi,the vice president of China real estate and housing research association Gu Yunchang,the director of Beijing University economy research institute Ju Guoyu,the director of National housing and urban-rural development research center Qing Hong,the famous economist Lang Xianping,the chairman of Hua Yuan real estate Co.,Ltd,stayed together to pulse the development of China real estate,to probe the real estate and capital market and to discuss the new developing mode of real estate in new circumstances.
The new type of urbanization construction was settled as the import topic,the expert expressed that the new type of urbanization shall be green and low carbon,this new mode will provide a new development opportunity of China green buildings. Therefore,the vice president of Beijing MICOE solar technology group Co.,Ltd. Zhang Shengyao was invited to a speech with the subject of using solar technology to innovate green building,he presented that solar energy is the important solution in green building and show the case of solar water heater integrated with building was highly praised by real estate agent.
During this meeting,MICOE was listed with the solution of systematized solar water heater integrated with building and contribution on green energy saving buildings,and was marked as outstanding real estate service enterprise.Vice President Zhang expressed that MICOE will base on hot water bank for cities,dominated by the solar thermal technology,integrated application of various energy saving technology and products,providing safe,convenient, and environmental protection hot water system projects,help cities to carry out energy conservation and emission reduction,providing safe,economic,clean and green energy to society,in order to achiever our green China Dream together.
( The vice minister of Jiang Su united front work department and party group secretary of the federation of industry and commerce Shao Jun )
( The director of National housing and urban-rural development research center Qing Hong )
( The vice president of Beijing MICOE solar technology group Co.,Ltd. Zhang Shengyao was making a speech )
( The vice CEO of MICOE Lu Jian was attending the round table discussion )
( MICOE was prized with outstanding real estate service enterprise )
( MICOE show room was highly concerned by real estate agent )
Many homeowners decide to install space heating heat pumps because of their high efficiency and reliability. By the way, the swimming pool heat pump is a kind of space heating heap pump as well, it heats the swimming pool though. It’s important to maintain your system in order to get the most out of your heat pump. Then, let us introduce more about the way to higher the efficiency of space heating heat pump.
Here is the content list:
How to make the space heating heat pump more efficient in the winter?
How to make the space heating heat pump more efficient at night?
Other tips on how to make the space heating heat pump more efficient.
When you adjust the thermostat during the winter months, don’t make big jumps upward or downward in the temperature setting. Sudden upward adjustments can activate the backup heater, which is inefficient. Remember that space heating heat pumps circulate air that will feel relatively cool coming out of the vent, but actually warm enough to heat the house efficiently. Unlike a gas furnace, which blasts hot air for a few minutes and then turns off, space heating heat pumps actually run longer, but are more cost-effective. The swimming pool heat pump needs to notice winter in a special way, be careful of the ice.
Further, setting the temperature back at night is not necessary for space heating heat pumps with two-stage thermostats. That is because turning the heat back up in the morning could activate the backup resistance heater, which would wipe out any energy savings from turning it down overnight. If you want to turn the temperature down at night for comfortable sleeping, slowly raise the setting a few degrees at a time in the morning and check the thermostat light to make sure backup heating has not been activated. Do not use a swimming pool heat pump all night, even since you sleep, it is not safe enough.
Make sure that your thermostat is properly paired with your space heating heat pump. Most “smart thermostats” are also designed to work with common space heating heat pump configurations. They also support several stages of heating and cooling and can run the space heating heat pump and auxiliary heat simultaneously to maximize comfort and reduce overall energy costs. Some systems are equipped with an outdoor temperature sensor, which is used by the logic to determine when supplemental heating is needed, even if the room thermostat is suddenly turned up. As a homeowner, remember to check the system air filters every month for dirt and dust, and clean or replace them as recommended. These air filters are very important to the system operating correctly, especially in homes with pets. Outdoor coils of space heating heat pump should also be cleaned with water regularly and checked to make sure that airflow around the unit is not obstructed by plants, mulch, garbage cans, or snow. Cleaning on the coils should only take place during warmer days, which may mean preparing in the fall season. If ice forms on the outside coil of a space heating heat pump during the winter season, know that this is completely normal, and no action needs to be taken. To melt the ice, the space heating heat pump has a defrost cycle, which should turn on automatically and melts the ice in less than 10 minutes. When this happens, steam might rise from the outdoor unit, which is also a normal part of the defrost cycle. Overall, maintaining good airflow both inside and outside will extend the life of your unit. The space heating heat pump should be serviced periodically, before the start of the heating season.
After knowing so much about higher the efficiency of space heating heat pumps, will you have more interest in it? If you are in the space heating heat pumps business, you can consider our cost-effective products.
